Plywood
Plywood
Plywood Manufacturing
Our plywood manufacturing factory is dedicated to producing top-quality plywood, blockboard, flush doors, and shuttering ply for a wide range of residential, commercial, and industrial applications. As a leading manufacturer in the wood panel industry, we utilize advanced manufacturing techniques and modern machinery to ensure every product meets the highest standards of strength and durability. Our experienced team oversees the entire production process — from raw material selection to final finishing — guaranteeing precision and consistency across all our plywood products. Whether you need durable shuttering ply for construction or premium flush doors and blockboard for interiors, our manufacturing unit is your trusted source for reliable, high-performance wood solutions.
Available Thicknesses
4mm | 6mm | 9mm | 12mm | 16mm | 19mm | 25mm
Product Highlights
Quinate Calibrated Technology (5 Times) for an ultra-smooth and even surface ✅ Conforms to IS: 710 (Marine Grade) standards for water-resistant durability ✅ Treated with ATBS Technology – Fully Borer & Termite Proof ✅ Anti-Fungal & Anti-Bacterial Coating for a hygienic, long-lasting product ✅ Fire Guard Technology – Fire resistance of no less than 45 minutes ✅ Resists Ignition, Surface Spread, and Penetration ✅ Manufactured with Imported High-Density Timber ✅ Uses Hydroxybenzene-Base Adhesive for superior bonding ✅ Core and veneers are chemically treated and composed ✅ Enhanced moisture resistance with Hydra Shield Technology ✅ Face Veneer Thickness: 0.5mm+ for added strength and smoothness ✅ Ideal for Structural and Engineering Applications
Technical Specifications—Pringle Plywood
Specification | Details |
Standard | IS:710 – Marine Grade |
Technology Used | 5-Time Quinate Calibrated for Uniform Thickness |
Surface Finish | Smooth, Long Calibrated Core |
Face Veneer Thickness | 0.5mm+ |
Termite & Borer Resistance | Yes (ATBS Technology Treated) |
Fungal & Bacterial Protection | Anti-Fungal and Anti-Bacterial Coating |
Fire Resistance | Fire Guard Technology – Resists Ignition, Spread, and Penetration for ≥45 mins |
Moisture Protection | Hydra Shield Technology |
Timber Type | Imported High-Density Timber |
Adhesive Used | Hydroxybenzene-Base Adhesive |
Formaldehyde Emission | Class E1 |
Retention of Preservation | Above 12 kg/m³ |
Density | Above 0.70 g/cm³ |
Moisture Content | 8–10% |
Hygroscopicity | Greater than 13% |
Rate of Burning | Greater than 40 minutes |
Nail Holding Strength | Greater than 120 Kgf |
Screw Holding Strength | Greater than 300 Kgf |
Glue Shear Strength (Dry State) | 1660 N |
Glue Shear Strength (Wet State) | 1400 N |
Tensile Strength (Face Grain) | Greater than 480 Kgf/cm² |
Sum of Strength Values | Greater than 960 Kgf/cm² |
Static Bending Strength (MOE) | 7800 N/mm² (Along Grain) / 4600 N/mm² (Across Grain) |
Wet Bending Strength (MOE) | >4800 N/mm² (Along Grain) / >3600 N/mm² (Across Grain) |
Modulus of Rupture (MOR) | >60 N/mm² (Along Grain) / >48 N/mm² (Across Grain) |
Thickness Tolerance | ±10% (up to 4mm) / ±5% (above 4mm) |
Adhesion of Plies | Excellent |
Load Bearing Capacity | Excellent |
Mycological Test | Pass / Complies with all relevant standards |
